ADCP-600-SC-FA4
Key Features:Self-contianed ADCP 600k
- Self-contained Unattended OperationBuilt-in lithium battery enables long-term, cable-free deployment for fixed-point monitoring. No external power required, ideal for remote and unattended field sites.
- High-Precision Shallow Water ProfilingDelivers accurate current measurements with ±0.3% ±3 mm/s precision and 1 mm/s resolution, optimized for shallow-to-medium depth rivers, reservoirs, and nearshore waters.
- Dual-Range Measurement & Bottom TrackingSupports both broadband (55 m) and narrowband (70 m) profiling, with bottom tracking from 0.8 m to 120 m, ensuring reliable data even in shallow and complex flow conditions.
- Flexible & High-Resolution ProfilingAdjustable cell layer thickness (0.5–4 m) with up to 255 measurement layers, allowing users to tailor vertical resolution for their specific monitoring needs.
- Rugged Titanium Alloy HousingLightweight and corrosion-resistant titanium construction, available in 1000 m, 3000 m, and 6000 m pressure ratings, built to withstand harsh marine environments.
Integrated Environmental & Attitude Sensors
Equipped with precision temperature, pressure, and attitude (roll/pitch/heading) sensors to maintain measurement accuracy in dynamic conditions.- Large On-Board Storage & Connectivity64 GB on-board Micro SD memory supports long-duration data logging, paired with RS-232/RS-422 interfaces for easy data retrieval and integration.
- Low Power Consumption for Extended DeploymentAverage power consumption ≤ 10 W ensures efficient operation and maximizes battery life during long-term unattended missions.
Overview
Specifications
| Technical Specification | 600kHz Self-contained ADCP |
|---|---|
| Operating Frequency | 600kHz |
| Operation Mode | Self-contained |
| Battery Type | Lithium Battery |
| Underwater Profile Range (Broadband / Narrowband) | 55m / 70m |
| Bottom Track Range | 0.8m - 120m |
| Current Measurement Accuracy | ±0.3% ± 3mm/s |
| Velocity Resolution | 1mm/s |
| Velocity Range | ±5.0 m/s (Default); ±20.0 m/s (Max) |
| Flow Direction Range | 0~360° |
| Flow Direction Accuracy | ±2° |
| Number of Cells | 1 - 255 |
| Height Measurement Resolution | 1mm |
| Height Measurement Accuracy | ±1% ± 0.5cm |
| Data Refresh Rate | 2Hz (No Bottom Track); 1Hz (With Bottom Track) |
| Cell Size | 0.5m - 4m |
| Beam Angle | 20° |
| Beam Width | 3.5° |
| Number of Beams | 4 Beams Janus |
| Internal Storage | 64 GB Micro SD Card |
| Communication Interface | RS-232 or RS-422 |
| Temperature Sensor | Range: -5°C to 45°C; Accuracy: ±0.1°C |
| Pressure Sensor | Range: According to depth rating; Accuracy: ±0.25% |
| Attitude Compass Sensor | Range: Roll ±85° | Pitch ±85° | Heading 0-360°; Accuracy (RMS): Roll 0.2° | Pitch 0.2° | Heading 0.8°; Resolution: 0.1° |
| Average Power Consumption | ≤10W |
| Operating Temperature | -5°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Power Supply Interface | 20V - 50V, 5A |
| Housing Material | Titanium Alloy |
| Weight (in Air / in Water) | 5.5 kg / 3.9 kg (1000m) | 6.8 kg / 6.4 kg (3000m) | 8.1 kg / 7.8 kg (6000m) |
| Dimensions (Excluding Top Connector) | Φ148 × 350 mm (1000m) | Φ148 × 357 mm (3000m) | Φ148 × 367 mm (6000m) |
| Available Options | - |
Applications
Ocean Observation
Oceanographic Research Vessel
AUV/ROV
Deepwater Oil and Gas
Renewable Energy
Cable and pipeline laying
Why Choose Us?
High Reliability
Continuous operation: ≥100 days
Small Size
Far smaller size than global counterparts with equal performance
Cost-Effective
Stable performance, affordable and reliable
Resources for Self-Contained ADCP Deployments
Everything you need to plan and execute a successful autonomous mooring deployment.
Best practices for polar and cold-region autonomous deployments
Every parameter decoded: what each spec means for your project
Buoys, tripods, and fixed platform configurations
Offshore wind: bankable current measurement strategy
Practical buyer’s analysis: performance, price, and service comparison
TCO perspective: deployment endurance, downtime, service
ADCP equipment consistency test report – independent validation data.
Frequently Asked Questions
About the ADCP-600-SC-FA4 Self-Contained ADCP
How long can the ADCP-600-SC-FA4 deploy autonomously?
Endurance depends on your sampling interval. See the Battery Life Estimator table above for detailed estimates. In burst mode at 1 burst per hour, deployments exceeding 180 days are achievable. External battery packs extend this to 1+ year. 64 GB storage handles years of data even at high sampling rates.
How is data recovered after a deployment?
After retrieval, connect via RS-232/422 cable to a PC and download using the free Oceantek ADCP Utility. Data exports to CSV, MATLAB, and Python formats. The 64 GB Micro SD stores months to years of data. For remote sites, optional acoustic modem telemetry provides periodic data subsets without retrieval.
What mooring configurations work best?
Three standard configurations: (1) Upward-looking bottom frame/tripod — most common for coastal sites. (2) Downward-looking from a surface buoy. (3) Mid-water in-line on a mooring. The unit auto-detects orientation. Read our mounting solutions guide for detailed diagrams.
